| Model / reference | Style | Connection | Drum Capability / Type | Drum Capability / Gallons | Drum Capability / Diameter (in) | Handle/Pump / Diameter (in) | Dimensions W x D x H (in) / Diameter (in) | Capacity (lb) / Diameter (in) | Weight (lb) / Diameter (in) |
|---|---|---|---|---|---|---|---|---|---|
| F88575C5 | Industrial | Beak | Universal | 30/55/85 | - | Hand Pump | 50 x 35 x 62 | 800 | 235 |
| F88577B3 | Industrial | Strap | Universal | 30/55 | 14 - 24 | Hand Pump | 50 x 35 x 62 | 800 | 255 |
| F89265 | Deluxe | Beak | Universal | 30/55/85 | - | Pallet Jack Style | (37-51) x (25-32) x 63 | 800 | 245 |
| F89264 | Deluxe | Strap | Universal | 30/55 | 14 - 24 | Pallet Jack Style | (37-51) x (25-32) x 63 | 800 | 265 |
| Documented model configurations | 4 |
|---|---|
| Drum Capability / Type | Universal |
| Capacity (lb) / Diameter (in) | 800 |
| Catalog feature / option | Ideal for picking drums from pallets and spill containment platforms. |
| Catalog feature / option | Heavy duty wheels create easy mobility for heavy loads. |
Source: 2025 storage and handling catalog, PDF page 35. Confirm the current selected configuration with your quote.
PRODUCT INFORMATION
Manual Drum Lift Transporters is presented here with the configurations documented in the 2025 storage and handling catalog. Use the comparison table to select the required capacity, dimensions and operating arrangement.
Catalog features and options: Ideal for picking drums from pallets and spill containment platforms.; Safely and ergonomically lift and maneuver drums throughout facility.; Reduce worker fatigue or possible injury.; Single mast design for maximum visibility.; Heavy duty wheels create easy mobility for heavy loads.; Backplate makes attachments interchangeable (additional attachments sold separately).; Heavy gauge steel construction.; Premium powder coat paint finish.; Ships fully assembled, ready to use..
Model and option notes: • Backplate makes attachments interchangeable (additional attachments sold separately)..
Reference: 2025 storage and handling catalog, PDF page 35. The tables reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Compare the documented model dimensions and capacities with your application. Include the selected reference, quantity, required load, power supply and site constraints with your request.
These specifications come from the 2025 storage and handling catalog. Ask for current model-specific drawings, installation requirements and any required compliance documents before ordering.
Choose a listed configuration or request selection help. Include quantity, application, delivery destination, unloading restrictions and your needed-by date.
Equipment details
Powered-Grip Manual-Drive Drum Rotators. Documented model configurations: 4. Drive / lift style: Semi-Powered. Drum connection: Grip.
Equipment details
Powered-Drive Strap Drum Rotators. Documented model configurations: 4. Drive / lift style: Fully Powered. Drum connection: Strap.
Equipment details
Powered-Drive Grip Drum Rotators. Documented model configurations: 4. Drive / lift style: Fully Powered. Drum connection: Grip.
