SKU 7-13764
GKS Robot 40 Lift Battery powered remote controlled transport system with integrated lift table
Battery powered remote controlled transport system with integrated lift table
- Power source
- Battery powered
- Loading height
- 9.8 inch
Open an image to inspect its original detail.
Specifications & options
| Model / configuration | Load Capacity | Raised Height | Lowered Height | End/Side Capacity | Std. Base & Platform | Maximum Platform | Lifting Speed | Shipping Weight |
|---|---|---|---|---|---|---|---|---|
| XBP24-10 | 1000 lbs | 33" | 9-1/4" | 1000 lbs | 24 x 36" | 30 x 42" | 10 sec | 470 lbs |
| XBP24-15 | 1500 lbs | 33" | 9-1/4" | 1500 lbs | 24 x 36" | 30 x 42" | 15 sec | 475 lbs |
| XBP24-20 | 2000 lbs | 41-1/2" | 17-1/2" | 2000 lbs | 24 x 36" | 48 x 48" | 15 sec | 700 lbs |
| XBP36-10 | 1000 lbs | 45" | 9-1/4" | 1000 lbs | 24 x 48" | 30 x 54" | 14 sec | 500 lbs |
| XBP36-15 | 1500 lbs | 45" | 9-1/4" | 1500 lbs | 24 x 48" | 30 x 54" | 20 sec | 505 lbs |
| XBP36-20 | 2000 lbs | 53-1/2" | 17-1/2" | 2000 lbs | 24 x 48" | 48 x 60" | 22 sec | 700 lbs |
| WBP24-10 | 1000 lbs | 33-1/4" | 9-1/4" | 1000 lbs | 36 x 36" | 42 x 42" | 8 sec | 590 lbs |
| WBP24-15 | 1500 lbs | 33-1/4" | 9-1/4" | 1500 lbs | 36 x 36" | 42 x 42" | 15 sec | 610 lbs |
| WBP36-10 | 1000 lbs | 45-1/4" | 9-1/4" | 1000 lbs | 36 x 48" | 48 x 54" | 14 sec | 650 lbs |
| WBP36-15 | 1500 lbs | 45-1/4" | 9-1/4" | 1500 lbs | 36 x 48" | 48 x 54" | 20 sec | 675 lbs |
| Manufacturer | Presto |
|---|---|
| Catalog range | XBP and WBP Portable Electric Lift Tables |
| Documented configurations | 10 |
Source: Presto General Catalog 2026, PDF page 19. Confirm the current selected configuration with your quote.
PRODUCT INFORMATION
Equipment overview
XBP and WBP use DC battery power and a hand pendant to position loads on a portable work surface.
Compare wide-platform variants with standard models by height and end/side rating. XBP24-20 and XBP36-20 use gravity lowering according to the source footnote; powered lowering should not be assumed for every model.
Documentation & drawings
Reference: Presto General Catalog 2026, PDF page 19. The tables reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Questions about this equipment
How do I choose a XBP and WBP Portable Electric Lift Tables configuration?
Compare wide-platform variants with standard models by height and end/side rating. XBP24-20 and XBP36-20 use gravity lowering according to the source footnote; powered lowering should not be assumed for every model.
What should I provide for a XBP and WBP Portable Electric Lift Tables quote?
For XBP and WBP Portable Electric Lift Tables, include the selected model or configuration, quantity, load size and weight, operating requirements, delivery address and needed-by date. Request current drawings, freight and installation details for that selection.
