SKU 7-13764
GKS Robot 40 Lift Battery powered remote controlled transport system with integrated lift table
Battery powered remote controlled transport system with integrated lift table
- Power source
- Battery powered
- Loading height
- 9.8 inch
Open an image to inspect its original detail.
Specifications & options
| Model / configuration | Load Capacity | Raised Height | Lowered Height | Std. Base & Platform | Maximum Platform | Lifting Speed | Standard Motor | Std. Voltage/ Phase/Hz | Shipping Weight |
|---|---|---|---|---|---|---|---|---|---|
| XL36D-40 | 4000 lbs | 43" | 7-1/4" | 48 x 48" | 72 x 72" | 34 sec | 1 HP | 115/1/60 | 1280 lbs |
| XL36D-80 | 8000 lbs | 43" | 7-1/4" | 48 x 48" | 72 x 72" | 44 sec | 1-1/2 HP | 230, 460/3/60 | 1340 lbs |
| XL36D-120 | 12000 lbs | 43" | 7-1/4" | 48 x 48" | 72 x 72" | 60 sec | 1-1/2 HP | 230, 460/3/60 | 1400 lbs |
| XL48D-40 | 4000 lbs | 55" | 7-1/4" | 48 x 64" | 72 x 96" | 64 sec | 1-1/2 HP | 230, 460/3/60 | 1600 lbs |
| XL48D-80 | 8000 lbs | 55" | 7-1/4" | 48 x 64" | 72 x 96" | 72 sec | 1-1/2 HP | 230, 460/3/60 | 1700 lbs |
| XL48D-120 | 12000 lbs | 55" | 7-1/4" | 48 x 64" | 72 x 96" | 78 sec | 1-1/2 HP | 230, 460/3/60 | 1800 lbs |
| XL60D-40 | 4000 lbs | 70" | 10" | 48 x 86" | 72 x 120" | 20 sec | 3 HP | 230, 460/3/60 | 2500 lbs |
| XL60D-80 | 8000 lbs | 70" | 10" | 48 x 86" | 72 x 120" | 40 sec | 3 HP | 230, 460/3/60 | 2650 lbs |
| XL60D-120 | 12000 lbs | 70" | 10" | 48 x 86" | 72 x 120" | 60 sec | 3 HP | 230, 460/3/60 | 2750 lbs |
| Manufacturer | Presto |
|---|---|
| Catalog range | XL Dual Scissor Lift Tables |
| Documented configurations | 9 |
Source: Presto General Catalog 2026, PDF page 21. Confirm the current selected configuration with your quote.
PRODUCT INFORMATION
Equipment overview
XL dual tables use adjacent mechanisms beneath a broad deck, serving loads that need width rather than a long narrow platform.
Compare square and rectangular decks with the workpiece, then select capacity and supply. Review loading across the whole platform instead of applying a tandem model's geometry.
Documentation & drawings
Reference: Presto General Catalog 2026, PDF page 21. The tables reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Questions about this equipment
How do I choose a XL Dual Scissor Lift Tables configuration?
Compare square and rectangular decks with the workpiece, then select capacity and supply. Review loading across the whole platform instead of applying a tandem model's geometry.
What should I provide for a XL Dual Scissor Lift Tables quote?
For XL Dual Scissor Lift Tables, include the selected model or configuration, quantity, load size and weight, operating requirements, delivery address and needed-by date. Request current drawings, freight and installation details for that selection.
